YTO-X1304
Хит
Characteristics
Engine model
—
LR6М5-23
Length × width by tires × height, mm
—
5050*2370*3030
Wheelbase, mm
—
2688,5
Maximum torque, N·m
—
496 Nm at 1500 rpm
Nominal power, kW / hp
—
103/140
Ground clearance, mm
—
470 8
YTO-X1304
#PROP_TITLE#
—
#PROP_VALUE#
Characteristics
|
Engine model
|
LR6М5-23 |
|
Length × width by tires × height, mm
|
5050*2370*3030 |
|
Wheelbase, mm
|
2688,5 |
|
Maximum torque, N·m
|
496 Nm at 1500 rpm |
|
Nominal power, kW / hp
|
103/140 |
|
Ground clearance, mm
|
470 8 |
|
Drive
|
Full (engageable) drive system. |
|
Engine
|
6-cylinder, inline, vertical, liquid-cooled, four-stroke, naturally aspirated engine. |
|
Engine displacement (cm³)
|
7700 |
|
Piston cylinder diameter × stroke (mm)
|
110*135 |
|
Nominal crankshaft speed (rpm)
|
2300 |
|
Air filter
|
Dry type |
|
Battery
|
12V, 120Ah |
|
Number of gears (forward/reverse)
|
12/4 |
|
Front counterweights (quantity (pcs.) × mass (kg))
|
12*50 |
|
Rear counterweights (quantity (pcs.) × mass (kg))
|
8*50 |
|
Front tires
|
14,9-26 3.981 |
|
Rear tires
|
18,4-38 |
|
Clutch diameter (inches)
|
13 |
|
Clutch type
|
Dry type |
|
Maximum lifting capacity (load point 610 mm behind suspension axle) kN
|
28 |
|
PTO rotation speed (rpm)
|
540/1000 |
|
Max. forward speed, km/h
|
2,19-29,6 3.2 |
Video
You can purchase equipment on an installment plan or lease. You can also submit a request—our manager will contact you to clarify the details.
